Specifications
Operating voltage: 5.00V DC
Working current: 40mA (MAX)
Response time: <500ms
Insulation resistance: 100MΩ (Min)
Output mode: analog output: 0~4.5V; digital output: high/low level signal (can adjust the potentiometer to select the corresponding threshold)
Operating temperature: -20 ° C ~ 90 ° C
Module size: 38.6mm*22.1mm
Sensor Interface: XH2.54 connector
Ratio Range (NTU): 0~1000±30
Infrared Emitting Diode: 940nm (Peak emission wavelength)
Photo Transistor: 880nm (Peak emission wavelength)
